Y1625S
YIZHOU
002
| Availability: | |
|---|---|
| Quantity: | |
Applicable Materials and Industry:
Conveyor system for each size, Optional for Electric Oscillating Tool, Pneumatic Oscillating Tool,
Driven Rotary Tool, CCD Camera Registration System, Autoloader, Projector, Nature Leather System
punching, creasing and marking functions with high seed and high precision. With autoloader, it can complete the material
with different cutting tools, suitable for different kind of materials.
Parameters
Model |
YZ1625S |
YZ1630S |
YZ1610S |
Working size | 1600*2500mm | 1600*3000mm | 1600*1000mm |
Max. Cutting Thickness | 0-50mm | ||
Cutting Head | EOT/DRT/POT for optional | ||
Working Table | Conveyor System | ||
Max.cutting speed | 0-1500mm/s | ||
Motion System | Digital servo motor & driver | ||
Repeat location accuracy | ± 0.01mm | ||
Voltage | AC220V/50HZ AC380V/50HZ 60HZ | ||
Media Fixture Method | Section Vacuum System | ||
Pump Power | 5.5KW/7.5KW/9KW/11KW | ||
Operating Environment | Temperature 0-40℃ Humidity 20%-80% RH | ||
User Control | Color Control panel & Touch Screen control Panel | ||
Software | YIZHOU CAD | ||
Format support | AI/DXF/DWG/JPG/BMP/PLT/DST CorelDraw/PhotoShop/AutoCAD/Illustrator | ||
Interface | USB/LAN/Serial Port | ||
Applicable Materials and Industry:
Conveyor system for each size, Optional for Electric Oscillating Tool, Pneumatic Oscillating Tool,
Driven Rotary Tool, CCD Camera Registration System, Autoloader, Projector, Nature Leather System
punching, creasing and marking functions with high seed and high precision. With autoloader, it can complete the material
with different cutting tools, suitable for different kind of materials.
Parameters
Model |
YZ1625S |
YZ1630S |
YZ1610S |
Working size | 1600*2500mm | 1600*3000mm | 1600*1000mm |
Max. Cutting Thickness | 0-50mm | ||
Cutting Head | EOT/DRT/POT for optional | ||
Working Table | Conveyor System | ||
Max.cutting speed | 0-1500mm/s | ||
Motion System | Digital servo motor & driver | ||
Repeat location accuracy | ± 0.01mm | ||
Voltage | AC220V/50HZ AC380V/50HZ 60HZ | ||
Media Fixture Method | Section Vacuum System | ||
Pump Power | 5.5KW/7.5KW/9KW/11KW | ||
Operating Environment | Temperature 0-40℃ Humidity 20%-80% RH | ||
User Control | Color Control panel & Touch Screen control Panel | ||
Software | YIZHOU CAD | ||
Format support | AI/DXF/DWG/JPG/BMP/PLT/DST CorelDraw/PhotoShop/AutoCAD/Illustrator | ||
Interface | USB/LAN/Serial Port | ||
