CNC Plasma Cutting Machine YZ1530
You are here: Home » Products » CNC Plasma Cutting Machine » CNC Plasma Cutting Machine YZ1530

CNC Plasma Cutting Machine YZ1530

Share to:
sharethis sharing button
cnc plasma cutting machine
1.seamless welding machine body
2.1500*3000mm working area
3.China LGK 120A Plasma source
4.Independent control cabinet
5.STARfire control system
6.Automatic Torch height controller
7.Starcam software
8.2GB processing file
9.high precision square guide rail
10.high precision ball screw
11.China high precision stepper motor
12.Multi-function tool box
13.water channel
14.20 sets of nozzle electrodes
15.Easy feeding slide material system
16.High quality soft electricity cable can be bend for 1.5 million times
17.Dust shield and anti-collision system
18.All the necessary parts for machine working
  • YZ1530




1530    63A-200A Plasma cutting machine (high configuration

X,Y working area


Z working area


Packing dimension


Lathe bed

Very thick steel structure

Machine Power


Working voltage

380V three phase 60hz

Reposition precision


Processing precision


Maximum cutting speed


Torch Height control mode


Cutting thickness

Max 25mm carbon steel

Plasma power supply

 LGK63A-200A   China plasma

Control system



Stepper motor





Plasma Air Pressure


Working Temperature

-10°C-60°C. Relative Humidity, 0-95%.

LCD Display Dimension

7 Inches

We do this line many years, have rich experience and professional knowledge, will let you get the most suitable machine with the right configuration. This ability can let you avoid many mistake and avoid some trouble. Other factory usually lack this experience, and bring some trouble for the real customer.


②If use the plasma cutting machine to cut the the thick meal, have to use the arc height adjust system, while our height adjust system use the high sensor, one minute can send out 12,000 signal per minute, while other height adjust system usually send out 10000 signal per minute, so our cutting quality more better than other factory and cutting speed a litter faster than the same power plasma source.


Fuselage water platform, smoke removal and dust removal effect is good


④ All our machines have to be checked three times, then allow to send out ,and finally will put one 8GB flash disk into the package, when the customer received the machine, can easy check the video from the 8GB flash disk ,then do the easy operation, in the video nearly like hand by hand do the teaching job, so can let the customer in the shot time to let the machine create the profit. While we also have the video platform, after you purchase the machine, we will give you one password, then you can easy to get the efficiency “after-sell service” from the internet. While other small factory usually, only check one time for the machine, and no 8GB flash disk, and no video platform, then it is hard for you to get the good after-sell service.

⑤ The painting: all our machine body have been processed by professional anti-rust treatment. First, we spray 2 times anti-rust paint to ensure that all parts of the machine in a fully protected state, and then spray color. This can effectively prevent the machine rust, resulting in damage to the machine. Other manufacturers do not take anti-rust treatment or only spay 1 time rust paint.

⑥ Just because our machine all equipped the professional parts, and test more seriously for the whole machine, so our guarantee period it is 2 years, while other factory it is only 1 years.


⑦ we will free provide 2G processing design (USD 320) and Australia professional metal cutting software for you, in the 2G processing design have thousand beautiful graphic, after you get the machine, you can let the machine do a lot of beautiful work, while no need find the engineer to help you to design.

⑧ Machine structure is designed by famous mechanical professor, to add many columns for each bean. So that the machine body can bear more weight for large, thick metal sheets without deforming. But some small factories will not add these parts for saving cost, their machine is easy to deform for thick metal.






If you have any questions, please feel free to contact us, we will give you a satisfactory answer.
