CCD Camera Vision Laser cutting machine
You are here: Home » Products » Laser Machine » CO2 Laser Cutting Machine » CCD Camera Vision Laser cutting machine
CCD Camera Vision Laser cutting machine CCD Camera Vision Laser cutting machine
CCD Camera Vision Laser cutting machine CCD Camera Vision Laser cutting machine

loading

CCD Camera Vision Laser cutting machine

Share to:
sharethis sharing button
Camera system good at contour cutting for sublimation,printed fabric,textile
  • YZ1610V

  • YIZHOU

  • 008

Model:
Working size:
Laser type:
Camera system:
Availability:
Quantity:


Name

Model

Model

YZ1810V

YZ1813V

YZ1610V

Price FOB

Negotiation

Negotiation

Negotiation

Working size

1800*100mm

1800*1300mm

1600*1000mm

Laser Tube

EFR120W-150

EFR120W-150W

EFR120W-150W

Laser Head no.

1

1

1

Max.prodution capacity

1800

pairs/8hours/per day

1800

pairs/8hours/per day

1800

pairs/8hours/per day

Packing size

2.35*2.3*1.3m

2.35*2.45*1.3m

2.2*2.15*1.3m

Water chiller

CW-5200

Laser foucs Lens

II-VI 25mm dia.

Laser reflected lens

II-VI 20mm dia.

Feeding

automatic Stainless convenyor belt

Positioning

Camera

Transmission

Linear rail+ONK belt

Air fan

550W*2

Table

3mm iron

Air compressor

0.8Mpa non-oil low-noise compressor

Motor

Stepper motor Leadshine

Driver

Stepper driver leadshine

Controller

 LaserCAD

Max.Engraving speed

64000mm/min

Max.Cutting speed

36000mm/min

Voltage

220V/50HZ/60HZ

Working Temperature

0-45 degree

Support format

BMP、AI、PLT、DST、DXF

Repeat Position Precision:

≤±0.05mm


CCD laser cutting machine with vision for sublimated dye textile

This laser cutting machine is equipped with advanced Vision system.Camera auto positioning and Laser cutting applied on printed fabric, such as digital printed apparel, sublimated sports garment, cycling clothes, racing suits, swimming suit, printed toys, carpet, home furnishing, banners, flags and so on.



Features

* Fast and Precise Cutting of Dye Sublimated Textiles

* No need to create cut designs

* Fabric deformation or printing error can still be cut accurately

* Cuts Any Type of Textile

VISION AUTO FEEDING LASER CUTTING MACHINE  APPLICATION

This model machine has multi function. special forflyknit,embroidery fabric, leather,PU shoes upper cutting,suitable for 1.5m width coiled printed textile materials.


VISION AUTO FEEDING LASER CUTTING MACHINE  ADVANTAGES

1. Fast cutting, use 150W powerful laser tube and double laser head, it can cut max.15mm thickness leather materials and finish 1800 pairs shoes per day for one set machine.

2. Full automatic. Automatic feeding materials, and conveyor belt, save labor time and working.

3. Cutting edge is perfect.

4. High quality parts,like II-VI lens,ONK belt,leadshine motors. Laser tube life reach to 10000 hours.

5. Multi function, Not only cutting, but also making holes,engraving.

6. No need mould for shoes making, save money and easy to operate.

7. All cutting size is accuracy.


Work Flow


Without the need for human intervention, Vision Laser machine can achieve continuous recognition and cutting of the entire roll printed fabrics.

002

< < Step 1: Various graphics printed on fabric and loaded to the laser cutter working table with our auto-feeder.

003



Step 2: Material information extracted by the HD SRL Camera> >



004


<< Step 3: The software recognize outer contour of graphics, then automatically create the cutting path

005




Step 4: Laser head cuts as the path in software>>


006


1577520304
